ECS P965T-A User Manual

22
Installing the Motherboard
USB1/2/3: Front Panel USB headers
The motherboard has four USB ports installed on the rear edge I/O port array. Additionally,
some computer cases have USB ports at the front of the case. If you have this kind of case,
use auxiliary USB connector to connect the front-mounted ports to the motherboard.
1 USBPWR Front Panel USB Power
2 USBPWR Front Panel USB Power
3 USB_FP_P0- USB Port 0 Negative Signal
4 USB_FP_P1- USB Port 1 Negative Signal
5 USB_FP_P0+ USB Port 0 Positive Signal
6 USB_FP_P1+ USB Port 1 Positive Signal
7 GND Ground
8 GND Ground
9 Key No pin
10 USB_FP_OC0 Overcurrent signal
Pin Signal Name Function
IR1: Infrared header
The motherboard supports an Infrared (IR1) data port. Infrared ports allow the wireless
exchange of information between your computer and similarly equipped devices such as
printers, laptops, Personal Digital Assistants (PDAs), and other computers.
Pin Signal Name Function
1 NC 2 KEY
3 VCC 5 4 Ground
5 IRTX 6 IRRX
Pin Signal Name
Pin Signal Name
CD_IN1: Analog Audio Input connector
Pin Signal Name Function
1 CD_Right CD In right channel
2 GND Ground
3 GND Ground
4 CD_Left CD In left channel

ECS P965T-A Specifications

General

Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA connectors	5
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Audio chip	Realtek ALC883
Certification	WHQL
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	-
On-board graphics card	No
Parallel processing technology support	Not supported
PCI Express x16 slots	2
Networking features	Gigabit Ethernet
BIOS type	Award
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	244 mm
Width	305 mm
