26
GB
Release the coupling by turning knob (C) counter-
clockwise and remove the attachment.
Approved power tool attachments (Fig.19)
The following Emak attachments may be mounted
to the basic power tool:
EH 24 Hedge trimmer (adjustable) (1) (2)
EH 48 Hedge trimmer (adjustable) (1) (2)
EP 100 Pole pruner (2)
Pruner attachment: D-PP (3)
Hedge trimmer attachment: D-HC (3)
Blower attachment: D-BV (3)
Extension attachment (3)
(1) Safety boom (A, Fig.9A) must be assembled
under the loop handle.
(2) Not approved for use with bike handle units (DS
2200 T – DS 2400 T).
(3) Approved for use with model DS 2400 D
5. STARTING
FUELING
WARNING: Gasoline is an extremely
ammable fuel. Use extreme caution when
handling gasoline or fuel mix. Do not smoke or
bring any re or ame near the fuel or the unit.
· To reduce the risk of fire and burn injury,
handle fuel with care. It is highly flammable.
· Mix and store fuel in a container approved for
gasoline.
· Mix fuel outdoors where there are no sparks or
flames.
· Select bare ground, stop engine, and allow to
cool before refueling.
· Loosen fuel cap slowly to release pressure and
to keep fuel from escaping around the cap.
· Tighten fuel cap securely after refueling. Unit
vibration can cause an improperly tightened
fuel cap to loosen or come off and spill
quantities of fuel.
· Wipe spilled fuel from the unit. Move 3 metre
away from refueling site before starting
- Insert screw (G) and tighten down rmly.
FITTING THE SAFETY GUARD (Fig.7)
- Insert the two pins (E) of the cutting attachment
guard, in the holes (F).
- Fit the blade guard (A) to the shaft arm with
screws in a position allowing the operator to
work safely (B).
NOTE: use the guard (C) only with nylon head.
Secure the guard (C) to the protection (A) by
means of the screw (D).
FITTING THE DISK (Fig. 9)
Loosen the bolt (A) clockwise; remove washer (B),
cup (D) and lower ange (E).
Fix the blade (R) onto the upper ange (F) making
sure that the rotation direction is correct.
Fix the lower ange (E), the cup (D), the washer (B)
and tighten bolt (A) anti-clockwise.
Put the pin provided in the appropriate hole (L) to
block the blade and allow the bolt (A, Fig. 2) to be
tightened to 2.5 kgm (25 Nm).
WARNING – Collar (see arrows C, Fig.9)
must locate in blade’s mounting hole.
WARNING! This machine is not suitable for
use with blade for wood (22-60-80 teeth) and
relevant metal guard.
WARNING: Make sure that all components
are connected properly and all screws tightened.
MOUNTING AND DEMOUNTING DS 2400 D
ATTACHMENTS (FIG.5A)
Mounting:
- Loosen coupling (E) by turning knob (C) counter-
clockwise;
- Align attachment tab (B) with channel (A) in
coupling (E);
- Fit attachment tube (D) into coupling (E) as far
as broken line (F);
NOTE To facilitate the procedure rotate the
attachment cutting tool to engage the drive shaft
with the tting. Check to ensure there is no dirt
or debris in the coupling;
- Tighten knob (C) fully by turning it clockwise.
Demounting:
