2. Move the oil tank aside; Remove the brake handle assembly.
3. Loosen the screw in the clamp and remove the clamp from the switch.
Description Part Number SPEC
Brake handle
3402731000
Brake Piece
3705658000
Clamp
3700367000
Tapping screw
5610042000
Replace the PCBA
Brake
handle
Brake Piece
Clamp
11
