Page #17 background imageLoading...
Page #17 background image
1. Insert the oil outlet into the oil hole of the housing.
2. Lock the oil pump in the housing with screw.
3. Mount the plastic gear onto the pin, make sure the
eccenter downwards
Assemble the Product
17
Oil outlet
Oil pump
Eccenter
Pump head
Oil hole
