elco VG 2.210 D User Manual

02/2011 - Art. Nr. 4200 1029 5200B14
Commissioning
Adjustment data
The adjustment values above are guide
values and facilitate commissioning.
The factory settings are in bold set
against a grey background The final
settings are essential in ensuring that
the burner functions as well as possible
Setting the gas pressure switch
• Remove the transparent cover.
• Provisionally set to 15mbar.
Setting the air pressure switch
• Remove the transparent cover.
• Provisionally set to 1 mbar.
1
st
sta ge 2
nd
sta ge
Ignit.
1
st
sta ge 2
nd
sta g e
50 80 15
12 12 30
20
55 110 20 17 17 80 30
601202020209030
60 110 5 15 15 40 25
70 140 10 18 18 50 30
90 160 35 20 20 60 40
80 150 10 20 20 52 35
90 170 25 22 22 70 45
90 180 35 25 25 82 45
110 210 35 25 25 90 45
A ir fla p se ttin g
VG 2.120 D
VG 2.160 D
2
d
stage
valve
opening
VG 2.210 D
Burner power
Dimension
Y
(mm)
