42
E30SO75ESS
PARTS LIST
*
*
*
*
Δ Δ
Δ Δ
Δ *
Note: The parts marked "
ΔΔ
ΔΔ
Δ" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY
ELECTRICAL PARTS
1 QSW-MA085WRE0 Secondary interlock/door sensing/damper switch 3
2 RMOTDA191WRE0 Damper motor 1
3 RHET-A263WRZZ Top heating element 1
4 RHET-A257WREZ Side heating element 1
5 FH-HZA053WRE0 Thermistor 1
6 RMOTCA011WREZ Convection motor 1
7 RMOTDA189WRE0 Turntable motor 1
8 FMOTEA459WRKZ Fan motor assy 2
9 FACCDA113WREZ Power supply cord 1
10 FH-DZA104WRKZ High voltage rectifier assy 1
11 RC-QZA235WRE0 High voltage capacitor 1
12 FFS-BA033WRKZ Monitor fuse 20A and monitor switch (V-5220Q) assembly 1
13 VHRG3NE22TL-1 Solid-state relay 2
14 QFS-CA026WRZZ Fuse F10A 1
15 QFS-TA014WRE0 Temperature fuse 150 deg. C (MG) 1
16 QFSHDA019WRE0 Fuse holder 1
17 RC-QZA324WRZZ convection motor capacitor 1
18 RLMPTA083WRZZ Oven lamp 1
19 RTHM-A109WRE0
Thermal cut out 170 deg.C(Top heater) 170deg.C OFF 155deg.C ON
1
20 RTHM-A110WRE0
Thermal cut out 150 deg.C(Side heater) 150deg.C OFF 130deg.C ON
1
21 RTRN-A678WRZZ Power transformer 1
22 RTRNPB021MRE0 LV transformer 1
23 RV-MZA288WRE0 Magnetron 1
24 FPWBFA370WRKZ Noise filter 1
CABINET PARTS
25 GCABDA104WRPZ Back plate 1
26 GDAI-A356WRWZ Bottom plate 1
27 GLEGPA092WREZ Leg 2
28 GCABUA976WRPZ Outer case cabinet 1
CONTROL PANEL PARTS
29 DPWBFB139MRU0 Power unit (
located on bottom plate
)1
30 DPWBFB138MRU0 CPU unit 1
31 FUNTKB449MRK0 Key unit 1
32 LX-CZB033MRE0 Special screw 8
OVEN PARTS
33 FDUC-A371WRKZ Damper duct assembly 1
34 PZETEA084WRFZ PWB mounting angle 1
35 LANGQA571WRPZ Motor mounting angle 1
36 MCAMPA102WRFZ Damper cam 1
37 NSFTTA143WREZ Damper shaft 1
38 PCUSGA604WREZ Damper cushion 1
39 PFTA-A033WRWZ Damper 1
40 LANG-A097WRPZ Catalyst angle 3
41 LANGFA242WRPZ Heater mounting angle A 1
42 PDUC-A821WRTZ Heater duct upper 1
43 PFIL-A020WREZ Catalyst 3
44 LANGFA260WRPZ Heater mounting angle B 1
45 PDUC-A822WRTZ Heater duct left 1
46 FANGTA167WRKZ Coupling assembly 1
47 FDUC-A369WRKZ Exhaust duct 1
48 FFANMA016WRKZ Convection fan assembly 1
49 LANGFA243WRPZ Convection motor mounting angle 1
50 PDUC-A825WRPZ Convection duct 1
51 PFPF-A229WREZ Thermal insulator back 1
52 PREFHA072WRWZ Thermal cover back 1
53 PSKR-A388WRWZ Divide plate A 1
54 PSKR-A389WRWZ Divide plate B 1
55 ************* Oven cavity (Not replaceable part) 1
56 LANG-A095WRPZ Turntable mounting angle 1
57 LANGQA569WRPZ Separator left 1
58 LANGQA590WRWZ Lamp mounting angle 1
59 PSKR-A387WRPZ Magnetron separator 1
To Next Page
