E30SO75ESS
ELECTROLUX HOME PRODUCTS, INC.
SERVICE MANUAL
ELECTROLUX
MICROWAVE OVEN
E30SO75ESS
FOREWORD
This Manual has been prepared to provide Electrolux Home Products
Service Personnel with Operation and Service Information for the
ELECTROLUX HIGH SPEED MICROWAVE OVEN, E30SO75ESS.
It is recommended that service personnel carefully study the entire
text of this manual so that they will be qualified to render satisfactory
customer service.
Check the interlock switches and the door seal carefully. Special
attention should be given to avoid electrical shock and microwave
radiation hazard.
WARNING
Never operate the oven until the following points are ensured.
(A) The door is tightly closed.
(B) The door brackets and hinges are not defective.
(C) The door packing is not damaged.
(D) The door is not deformed or warped.
(E) There is not any other visible damage with the oven.
Servicing and repair work must be carried out only by trained service
personnel.
DANGER
Certain initial parts are intentionally not grounded and
present a risk of electrical shock only during servicing.
Service personnel - Do not contact the following parts while
the appliance is energized;
High Voltage Capacitor, Power Transformer, Magnetron,
High Voltage Rectifier Assembly, High Voltage Harness;
If provided, Vent Hood, Fan assembly, Cooling Fan Motor.
All the parts marked “*” on parts list are used at voltages more than
250V.
Removal of the outer wrap gives access to voltage above 250V.
All the parts marked “ ” on parts list may cause undue microwave
exposure, by themselves, or when they are damaged, loosened
or removed.
PRODUCT DESCRIPTION
GENERAL INFORMATION
OPERATION
TROUBLESHOOTING GUIDE
AND TEST PROCEDURE
TOUCH CONTROL PANEL
COMPONENT REPLACEMENT AND
ADJUSTMENT PROCEDURE
WIRING DIAGRAM
PARTS LIST
