22 Maintenance
14. Remove the top clamp from the vent
tube, for easier access for the air
hose.
15. Apply air pressure (approximately 10
psi) to the end of the vent tube which
will purge the remainder of the water
from the drain pump and the drain
line (Figure 6).
16. Reinstall the vent tube and clamp
to the back of the ice machine and
remove the winterization plug from
the ice bin and save it for future use.
To Restart the Ice Machine
1. Reconnect or turn on the water
supply line.
2. Reconnect drain tubing if removed.
3. Plug in the power cord to a wall
outlet and turn the ice machine on.
4. Check the water inlet, drain lines, and
fittings for any water leaks.
5. Check drain pump (if equipped)
operation by pouring approximately
two quarts of water into the ice
storage bin. The drain pump should
activate and discharge water (refer to
Drain Pump section). Check for water
leaks at all hose connections.
Figure 6
Vent
tube
Drain
line
Remove
clamp
screw
