Element ELCHW321 Service Manual

Element (ELCHW321) 32 inch LCD Television Service Manual
Proprietary & Confidential Page 19
8. Parts Lists
ELEMENT ELCHW321 Parts list
No. Part No. Part Name Description Category
1
122149 Main board RSAG2.908.1553-3\ROH P1
2
119904 Power board RSAG2.908.1400- 1\ROH P1
3
116295 IR board RSAG2.908.1260-2\ROH P1
4
113354 Key pad RSAG2.908.1088\ROH P1
5
1044276 LVDS cable HX-0145\ROH P1
6
1041171 Speakers wire TJC3H-4Y-400-600\ROH P1
7
1055278 Speakers YDT5016-10W8R-H\ROH P1
8
1051636 Power cord YS-05+YS-22A\ROH P1
9
1060618 Remote control EN-31607E\ROH P1
10
1049482 Stand WG6.121.054\H1\ROH P2
11
1051735 Front bezel RSAG8.074.553\Z1\ROH P2
12
1048975 Light window RSAG8.640.065\ROH P2
13
1051723 Back cover RSAG8.074.524\Z1\ROH P2
14
1051670 Side label RSAG8.804.3293\ROH P2
15
1057588 Bottom label RSAG8.804.3429\ROH P2
16
1060488 Rating label RSAG8.807.4341\ROH P2
17
1049943 Stand hole cover RSAG8.634.064\Z0\ROH P3
18
1028377 Accessories bag RSR8.840.049\ROH P3
19
1028375 Stand screw bag RSAG8.840.016\ROH\STD P3
20
1028333 Battery LR03(7#)\ROH P3
21
1056131 Upper foam RSAG8.870.1336\ROH P3
22
1056132 Below foam RSAG8.870.1337\ROH P3
23
1060414 TV box RSAG6.875.4373\ROH P3
24
1036391 Cover RSAG8.634.047\ROH P3
25
1060853 User manual IES090555\ROH P3
26
1052403 Quick start guide IEB080507\ROH P3
27
1052079 Service page IEB080503\ROH P3
28
1052249 CHILD SAFETY English IEB080506\ROH P3
29
1052734 CHILD SAFETY Spanish IEB080510\ROH P3
30
1044923 Remote code guide English IES070520\ROH P3
31
1052733 Remote code guide Spanish IEB080509\ROH P3
32
1060848 Warranty card English IEB090503\ROH P3
33
1060849 Warranty card Spanish IEB090504\ROH P3
Note Description
P1 Main electronic parts for service.
P2 Cosmetic parts, mainly used in refurbishing.
P3 Package or refurbishing parts, most of it is used in refurbishing.

Element ELCHW321 Specifications

General

Brand	Element
Model	ELCHW321
Category	TV
Language	English
