Elo TouchSystems 1000 Series User Manual

Preset Modes
To reduce the need for adjustment for different modes, the monitor has default setting modes that
are most commonly used as given in the table below. If any of these display modes are detected, the
monitor automatically adjusts the picture size and centering. When none of the mode is matched,
the user can store their preferred modes in the user modes. The monitor is capable of storing up to
7 user modes. The only condition to store as a user mode is the new display information must have
1 KHz difference for horizontal frequency or 1 Hz for vertical frequency or the sync signal
polarities are different from the default modes.
H. Freq. Band Width
Mode Resolution (KHz) (MHz) H V
1 VGA 640x350 70 Hz 31.47 28.322
2 VGA 720x400 70 Hz 31.47 28.322
3 VGA 640x480 60 Hz 31.47 25.175
4 MAC 640x48066 Hz 35.00 32.24 - -
5 VESA 640x480 72 Hz 37.86 31.5 - -
6 VESA 640x480 75 Hz 37.50 31.5 - -
7 VESA 800x600 56 Hz 35.16 36 + +
8 VESA 800x600 60 Hz 37.88 40 + +
9 VESA 800x600 75 Hz 46.88 49.5 + +
10 VESA 800x600 72 Hz 48.08 50 + +
11 MAC 832x624 75 Hz 49.72 57.283 - -
12 VESA 1024x768 60 Hz 48.36 65 - -
13 SUN 1024x768 65 Hz 52.45 70.49 - -
14 VESA 1024x768 70 Hz 56.48 75 - -
15 VESA 1024x768 75 Hz 60.02 78.75 + +
3-21

Elo TouchSystems 1000 Series Specifications

General

Brand	Elo TouchSystems
Model	1000 Series
Category	Monitor
Language	English
