Elo TouchSystems 1000 Series User Manual

Touchmonitor Specifications
Model ET1537L
LCD Display 15” TFT Active Matrix Panel
Display Size 304.(H) x 228.(V) mm
Pixel Pitch 0.297(H) x 0.297(V) mm
Display Mode VGA 640 x 350 (70Hz)
VGA 720 x 400 (70Hz)
VGA 640 x 480 (60 / 72/ 75Hz)
SVGA 800 x 600 (56 / 60 / 72/ 75Hz)
XGA 1024 x 768 (60 / 70 / 75Hz)
Max. Resolution XGA 1024 x 768 at 75Hz maximum
Contrast Ratio 400 : 1 (typical)
Brightness Nontouch: typical 250 Cd/m
2
; Min 200 Cd/m
2
AccuTouch: typical 205 Cd/m
2
; Min 164 Cd/m
2
IntelliTouch: typical 230 Cd/m
2
; Min 184 Cd/m
2
Surface Capacitive: typical 205 Cd/m
2
; Min 164 Cd/m
2
Response Time Tr: 5 ms Tf: 12ms (Typ.)
Display Color 16.2M
Viewing Angle Vertical -60
o
~ +40
o
Horizontal -60
o
~+60
o
Input Signal Video R.G.B. Analog 0.7Vp-p, 75 ohm
Sync TTL Positive or Negative
Signal Connector Mini D-Sub 15 pin
Front Control Menu, , , Select, Power
OSD Contrast, Brightness, H-Position, V-Position,
Color Temperature, Phase, Clock, OSD Time, Recall,
Language: English, French, German, Spanish, Japanese
Plug & Play DDC1 / 2B
Touch Panel (optional) AccuTouch /IntelliTouch/Surface Capacitive.
Power Adapter Input AC 100-240V, 50-60Hz
Operating Conditions Temperature 0
o
C ~ 40
o
C (32
o
F ~ 104
o
F)
Humidity 20% ~ 80% (No Condensation)
Altitude To 12,000 Feet
Storage Conditions Temperature -20
o
C ~ 60
o
C (-4
o
F ~ 140
o
F)
Humidity 10% ~ 90% (No Condensation)
Dimensions (HxWxD) 336 x 264 x 41.2mm
Weight (Net) 3Kg
Certifications UL, C-UL, FCC-B, CE, VCCI, C-Tick, MPRII , S(Semko)
C-30 User Guide
