Technical data
Medium temperature
Low temperature
Family ZXV
Model name ZXV075BP ZXV090BP ZXV065BE ZXV085BE
Refrigerant R410A R404A
Evap temperature range °C -15°C ~ 10°C -20°C ~ 5°C
Ambient range °C -25°C ~ 48°C
Perfor-
mance
Maximum capacity
-10°C ET/40°C
AT/18°C RGT
kW 7.5 9.0 6.5 8.5
Nominal capacity
-10°C ET/32°C
AT/18°C RGT
kW 5.7 8.4 6.1 7.9
Nominal COP W/W 2.45 2.21 2.44 2.32
Nominal speed RPM 3000 RPM 4500 RPM 4500 RPM 4500 RPM
Compres-
sor
Model name ZBW030DP-4X9 ZBW030DP-4X9 ZBW030DE-4X9 ZBW038DE-4X9
Max input ampere Amp 15 22 15 22
Oil type Amp POE POE POE POE
Oil charge volume Liters 1.63 1.63 1.63 1.63
Speed range RPM 1800 - 4800 1800 - 5400 1800 - 6000 1800 - 6000
Fan
motor
Number of fan 1 1 1 1
Diameter mm 450 450 450 450
Max speed RPM 933 933 933 933
Max flow Total m
3
/h 3483 3483 3483 3483
Max fan motor power Input W 145 145 145 145
Others
Oil seperator Volume Liters 0.5 0.5 0.5 0.5
Receiver volume kg 4.3 4.3 4.3 4.3
Pipes
Suction OD Inch 3/4 3/4 3/4 3/4
Liquid OD Inch 1/2 1/2 1/2 1/2
Dimension W X H X D mm 1029 x 424 x 840 1029 x 424 x 840 1029 x 424 x 840 1029 x 424 x 840
Weight
Net kg 101 101 101 104
Gross kg 139 139 139 139
Family ZXLV
Model name ZXLV030BE ZXLV040BE
Refrigerant R404A
Evap temperature range °C -40°C ~ 0°C
Ambient range °C -25°C ~ 48°C
Performance
Maximum capacity
-32°C ET/40°C
AT/5°C RGT
kW 3.20 4.10
Nominal capacity
-32°C ET/32°C
AT/5°C RGT
kW 2.64 3.34
Nominal COP W/W 1.24 1.20
Nominal speed RPM 4500 RPM 4500 RPM
Compressor
Model name ZFW030DE-4X9 ZFW038DE-4X9
Max input ampere Amp 15 22
Oil type Amp POE POE
Oil charge volume Liters 1.63 1.63
Speed range RPM 1800 - 6000 1800 - 6000
Fan motor
Number of fan 1 1
Diameter mm 450 450
Max speed RPM 933 933
Max flow Total m
3
/h 3483 3483
Max fan motor power Input W 145 145
Others
Oil seperator Volume Liters 0.5 0.5
Receiver volume kg 4.3 4.3
Pipes
Suction OD Inch 3/4 3/4
Liquid OD Inch 1/2 1/2
Dimension W X H X D mm 1029 x 424 x 840 1029 x 424 x 840
Weight
Net kg 101 104
Gross kg 139 139
