CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps for the
cabinet parts, and the CBA in order to gain access to
item(s) to be serviced. When reassembling, follow the
steps in reverse order. Bend, route and dress the
cables as they were.
2. Disassembly Method
Note:
(1) Order of steps in procedure. When reassembling,
follow the steps in reverse order. These numbers
are also used as the Identification (location) No. of
parts in figures.
(2) Parts to be removed or installed.
(3) Fig. No. showing procedure of part location
(4) Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or
desoldered.
N = Nut, L = Locking Tab, S = Screw,
CN = Connector
* = Unhook, Unlock, Release, Unplug, or Desolder
e.g. 2(S-2) = two Screws (S-2),
2(L-2) = two Locking Tabs (L-2)
(5) Refer to the following "Reference Notes in the
Table."
Step/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Unclamp/
Desolder
Note
[1]
Stand Base
Plate
D1 4(S-1), 3(S-2), 4(S-3) ---
[2]
Stand
Cover
D1 --------------- ---
[3]
Stand
Hinge
D1 --------------- ---
[4]
Rear
Cabinet
D1 12(S-4), 2(S-5), 2(S-6) ---
[5] Shield (T) D2 (S-7), (S-8), (N-1) ---
[6] Shield Box D2
2(S-9), 3(S-10),
4(S-11)
---
[7]
Digital Main
CBA Unit
D2
D5
*CN3601, *CN3701,
*CN3704, *CN4501,
*CN4502
---
[8]
Power
Supply
CBA
D2
D5
7(S-12), *CN102,
*CN501, *CN801,
*CN802, *CN1901
---
[2] Stand Cover
[14] Junction-A
CBA
[17] Speaker
Holder (L,R)
[18] Speaker(s)
[3] Stand Hinge
[16] Function CBA
[10] Junction-B
CBA
[7] Digital Main
CBA Unit
[1] Stand Base
Plate
[4] Rear Cabinet
[5] Shield (T)
[12] Stand Holder
[6] Shield Box
[15] IR Sensor
CBA
[9] Inverter CBA
[11] PCB Holder
(L,R)
[13] LCD Module
Assembly
[19] Front Cabinet
[8] Power Supply
CBA
[9]
Inverter
CBA
D3
D5
7(S-13), *CN1050,
*CN1100, *CN1150,
*CN1200, *CN1250
---
[10]
Junction-B
CBA
D3
D5
Desolder ---
[11]
PCB Holder
(L,R)
D3 4(S-14) ---
[12]
Stand
Holder
D3 2(S-15), 2(S-16) ---
[13]
LCD
Module
Assembly
D4 4(S-17) ---
[14]
Junction-A
CBA
D4
D5
Desolder ---
[15]
IR Sensor
CBA
D4
D5
2(S-18), *CL102A ---
[16]
Function
CBA
D4
D5
2(S-19) ---
[17]
Speaker
Holder
(L,R)
D4 4(S-20) ---
[18] Speaker(s) D4 --------------- ---
[19]
Front
Cabinet
D4 --------------- ---
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
Step/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Unclamp/
Desolder
Note
