20080213 12-1 A8AF1CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1 FRONT CABINET A8AF1UH 1EM022265
A3 CONTROL PLATE A8AF0UH 1EM323600
A4 REAR CABINET A8AF1UH 1EM022266
A6# RATING LABEL A8AF1UH ----------
A7 FUNCTION KNOB A8AF0UH 1EM122273
A9 STAND COVER A8AF1UH 1EM122413
A10 REAR COVER A8AF0UH 1EM323717
A11 LED LENS A8AF1UH 1EM323799
A12 STAND RUBBER FOOT L5001CB 1EM423855
A26 LOGO LABEL A8AF1UH ----------
B1 PCB HOLDER (L) A8AF0UH 1EM122274
B2 PCB HOLDER (R) A8AF0UH 1EM122275
B3 SHIELD BOX A8AF0UH 1EM222004
B4 SHIELD (T) A8AF0UH 1EM323599
B7 STAND BASE PLATE A8AF0UH 1EM122276
B8 STAND HINGE A8AF0UH 1EM323598
B9 STAND HOLDER 32V A8AF0UH 1EM222005
B10 STAND HOLDER A81N0UH 1EM322709
B11 SPEAKER HOLDER (L) A8AF1UH 1EM323480
B12 SPEAKER HOLDER (R) A8AF1UH 1EM323800
B22 CLOTH(10X180XT0.5) L0336JG 0EM408827
B30 GASKET A8AF0UH 1EM425861
B40 WASHER(D17) A73F2FP 1EM425638
CL801 WIRE ASSEMBLY 005 2PIN / 170MM / AWG24 WX1A8AF0-005
CL802 WIRE ASSEMBLY 005 2PIN / 170MM / AWG24 WX1A8AF0-005
CL4501 WIRE ASSEMBLY 010 55PIN / 60MM WX1A8AF0-010
CL4502 WIRE ASSEMBLY 010 55PIN / 60MM WX1A8AF0-010
L2 SCREW P-TIGHT M4X14 BIND HEAD+BLK GBHP4140
L4 SCREW P-TIGHT M3X12 DISH HEAD+ GDJP3120
L6 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L9 SCREW S-TIGHT M3X4 BIND HEAD+BLK GBHS3040
L10 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L13 DOUBLE SEMS SCREW M4X6 M4X6 FPJ34060
L15 DOUBLE SEMS SCREW M4X10 + BLK FPH34100
L17 ASSEMBLED SCREW ( D9 M3X6 ) A71F0UH 1EM424392A
L18 NUT 3/8-32UNEF 0EM401451A
LCD1 32INCH LCD MODULE LCD 32INCH UG320XA
SP801 SPEAKER MAGNETIC S0412F06A DSD0809XQ006
SP802 SPEAKER MAGNETIC S0412F06A DSD0809XQ006
PACKING
S1 CARTON A8AF1UH 1EM425737
S2 STYROFOAM TOP A8AF1UH 1EM022366
S3 STYROFOAM BOTTOM A8AF1UH 1EM022367
S4 SET BAG A71FCUH 1EM323657
S5 RFID LABEL P7100UM ----------
S16 STAND BAG A71FCUH 1EM425338
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2# OWNERS MANUAL A8AF1UH 1EMN22959
X3 REMOTE CONTROL NF027UD 170/
ECNLC6.501/NF027
NF027UD
X4 DRY BATTERY(SUNRISE) R6SSE/2S XB0M451MS002
X5 SCREW BAG A81N0UH 1EM424596A
X6 QUICK SETUP GUIDE A8AF1UH 1EMN22999A
Ref. No. Description Part No.
