12
EN
P
REPARATION
rear of this unit
1
1
stand shafts
2
1
Spread a thick and soft cloth over a table. Place the
main unit face down onto it. Make sure not to damage
the screen. At least two people are required at this step.
Note:
• Make sure to use a table which can support the weight of
this unit and is larger than this unit.
• Make sure the table is in a stable location.
2
Remove the stand shafts from this unit.
Unscrew the M5 screws indicated by
1
and remove the
stand shafts. Please be careful with the unit after you
remove the stand shafts.
Note:
• The M5 screws and stand shafts you have removed are
necessary for reattachment at a later date. Make sure to
keep them in a safe place.
3
Attach the monitor brackets to this unit using the
M6 screws included with the wall mount kit.
Note:
• Only use the screw holes indicated by
2
for mounting this
unit.
• For instructions on how to attach the monitor plate, refer
to the instruction manual included with the wall mount kit.
4
Attach this unit to the wall. At least two people are
required at this step.
Note:
• Refer to the instruction manual included with the wall
mount kit when securing this unit to the wall.
*
1
and
2
indicate the position of the screw holes on this unit.
Attaching a Wall Mount Bracket (sold separately)
The following is a description of the method for attaching a wall mount to this unit.
When performing this operation, refer to the instruction manual included with the wall mount kit.
#
CAUTION
• Any damage caused by incorrectly attempting to mount this unit is
not covered under the terms of the manufacturers warranty.
• This unit may be used only with VMPL manufactured by SANUS SYSTEMS.
• Use with other wall mounts may result in instability causing possible injury.
You need the following wall mount kit for this unit.
Flat panel TV wall mount
Model number: VMPL
For more information,
please visit SANUS SYSTEMS website at www.sanus.com
5
To Next Page
