Emerson Micro Motion 800 User Manual

11 Model 1700/2700 transmitter 9-wire
integral installations
Table 11-1: List of Drawings for Transmitter Models 1700/2700 9-wire integral
installations
Drawing name Location
EB-20001058 Revision C Model 1700/2700 transmitter with integrally-mounted processor to
junction box on CMF, F, H, T, D, and DL sensors
EB-30006199, Revision A Model 1700/2700 transmitter with integrally-mounted core
processor to 9-wire junction box on CMF400 sensor with booster
amplifier
EB-10005117, Revision A Model 1700/2700 transmitter with integrally-mounted core
processor to junction box on D600 sensor
EB-36000538, Revision A Model 1700/2700 transmitter with integrally-mounted core
processor to 9-wire junction box on DT sensor
Installation Manual Model 1700/2700 transmitter 9-wire integral installations
MMI-20001965 October 2018
Installation Instructions 55
