Table 12-35 Siba branch circuit fusing for size 2 drives
Fuses are only rated up to 500Vac.
Table 12-36 Siba DC protection fusing for size 2 drives
DC fusing is only required on four quadrant (R) drives.
* Applications limited to 100% current ripple content and no cyclic overloads to avoid fuse wear-out
Model
International
Description Part number
Aux
*500Vac, 20A gG NH-Knife Blade
690Vac, 20A gG NH-Knife Blade
20 000 13.20
20 477 13.20
MP350A4(R)
*500Vac, 355A gG NH-knife blade
690Vac, 355A gG NH-knife blade
20 004 13.355
20 212 13.355
MP350A5(R)
MP350A6(R)
690Vac, 355A gG NH-knife blade 20 212 13.355
MP420A4(R)
*500Vac, 400A gG NH-knife blade
690Vac, 400A gG NH-knife blade
20 004 13.400
20 212 13.400
MP470A5(R)
MP470A6(R)
690Vac, 630A gG NH-knife blade 20 225 13.630
MP550A4(R) 690Vac, 630A gG NH-knife blade 20 225 13.630
MP700A4(R)
*500Vac, 800A gG NH-knife blade
690Vac, 800A gG NH-knife blade
20 006 13.800
20 225 13.800
MP700A5(R)
MP700A6(R)
690Vac, 800A gG NH-knife blade 20 225 13.800
MP825A4(R)
MP825A5(R)
MP825A6(R)
690Vac, 800A gG NH-knife blade 20 225 13.800
MP900A4(R) *500Vac, 1250A gG NH-knife blade 20 006 13.1250
MP1200A4(R) *500Vac, 1250A gG NH-knife blade 20 006 13.1250
NOTE
Model Description
International USA
Part number
Metric thread Blade contact UNC thread Blade contact
MP350A4R 2 x SQB3 1250V 315A in parallel.
2078132.315A. 2073532.315A 2078432.315A 2073932.315A
MP350A5R
MP350A6R
SQB3 1250V 400A
*2078132.400A. *2073532.400A *2078432.400A *2073932.400A
MP420A4R SQB3 1250V 500A
*2078132.500A *2073532.500A *2078432.500A *2073932.500A
MP470A5R
MP470A6R
2 x SQB3 1250V 315A in parallel.
*2078132.315A. *2073532.315A *2078432.315A *2073932.315A
MP550A4R 2 x SQB3 1250V 315A in parallel.
*2078132.315A. *2073532.315A *2078432.315A *2073932.315A
MP700A4R 2 x SQB3 1250V 500A in parallel.
2078132.500A 2073532.500A 2078432.500A 2073932.500A
MP700A5R
MP700A6R
2 x SQB3 1250V 450A in parallel.
*2078132.450A *2073532.450A *2078432.450A *2073932.450A
MP825A4R
MP825A5R
MP825A6R
2 x SQB3 1250V 500A in parallel.
*2078132.500A *2073532.500A *2078432.500A *2073932.500A
MP900A4R 2 x SQB3 1250V 500A in parallel.
*2078132.500A *2073532.500A *2078432.500A *2073932.500A
NOTE
