Quick Panel Operator User Manual Section 2
GFK-2847AA Jan 2023
Hardware 16
2.2.2 Ethernet Port Operation LEDs
The Ethernet port has two LED indicators: Speed and Link Activity.
LED
LED State
Operating State
Speed
Yellow, on
10/100
Link Activity
Green, on
Link status
