20020205 3-3-1 T7300EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
MMA CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
MMA CBA (MAIN+CRT+SENSOR) 0ESA04510
Consists of the followings
MAIN CBA (MMA-A)
CRT CBA (MMA-B)
SENSOR CBA
------------
------------
0ESA04524
Ref. No. Description Part No.
MAIN CBA (MMA-A)
Consists of the followings
------------
CAPACITORS
C002 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C003 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C004 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZB0F103
C005 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C006 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C007 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C205 CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C207 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C208 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C209 CHIP CERAMIC CAP. B K 0.022µF/50V or CHD1JKB0B223
CHIP CERAMIC CAP. B K 0.022µF/25V CHD1EKB0B223
C210 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C212 CHIP CERAMIC CAP.(MELF) SL J 22pF/50V CZM1JJBSL220
C213 CHIP CERAMIC CAP.(MELF) SL J 22pF/50V CZM1JJBSL220
C214 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C216 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZB0F103
C217 CHIP CERAMIC CAP.(MELF) SL D 10pF/50V CZM1JDBSL100
C218 CHIP CERAMIC CAP.(MELF) SL J 15pF/50V CZM1JJBSL150
C220 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C221 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZB0F103
C222 CHIP CERAMIC CAP.(MELF) Y K 2200pF/35V CZM1GKB0Y222
C223 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C224 CHIP CERAMIC CAP.(MELF) Y K 1000pF/35V CZM1GKB0Y102
C225 CHIP CERAMIC CAP.(MELF) W K 560pF/50V CZM1JKB0B561
C231 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C232 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C235 CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C236 CERAMIC CAP.(AX) F Z 0.047µF/16V CCA1CZTFZ473
C238 CHIP CERAMIC CAP.(MELF) Y K 1000pF/35V CZM1GKB0Y102
C239 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M CE1JMASTL220
C240 CHIP CERAMIC CAP.(MELF) W K 560pF/50V CZM1JKB0B561
C241 CHIP CERAMIC CAP.(MELF) Y K 4700pF/16V CZM1CKB0Y472
C242 CHIP CERAMIC CAP.(MELF) Y K 1000pF/35V CZM1GKB0Y102
C243 ELECTROLYTIC CAP. 22µF/16V M LL or CE1CMASLL220
ELECTROLYTIC CAP. 22µF/16V M LL CE1CMASLH220
C244 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZB0F103
C245 ELECTROLYTIC CAP. 47µF/25V M or CE1EMASDL470
ELECTROLYTIC CAP. 47µF/25V M CE1EMASTL470
C246 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZB0F103
C247 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M CE1JMASTL220
C251 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZB0F104
CHIP CERAMIC CAP. F Z 0.1µF/25V CHD1EZB0F104
C252 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/16V M CE1CMASTL471
C253 CERAMIC CAP.(AX) B K 100pF/50V CCA1JKT0B101
C255 ELECTROLYTIC CAP. 100µF/10V M or CE1AMASDL101
ELECTROLYTIC CAP. 100µF/10V M CE1AMASTL101
C256 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/16V M CE1CMASTL471
C257 CHIP CERAMIC CAP.(MELF) Y K 1000pF/35V CZM1GKB0Y102
C301 ELECTROLYTIC CAP. 1µF/50V M LL or CE1JMASLL010
ELECTROLYTIC CAP. 1µF/50V LL CE1JMASLH1R0
C302 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C304 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M CE1CMASTL221
C305 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C306 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL010
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C307 ELECTROLYTIC CAP. 100µF/10V M or CE1AMASDL101
ELECTROLYTIC CAP. 100µF/10V M CE1AMASTL101
C308 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C309 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C310 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C311 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C314 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL010
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C317 CHIP CERAMIC CAP. B K 0.022µF/50V or CHD1JKB0B223
CHIP CERAMIC CAP. B K 0.022µF/25V CHD1EKB0B223
C318 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL010
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C319 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL010
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C320 ELECTROLYTIC CAP. 100µF/10V M or CE1AMASDL101
ELECTROLYTIC CAP. 100µF/10V M CE1AMASTL101
C322 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL010
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
