EN-7100e
20
31MY02
EN-7100e
Appendix
Connector Pin Assignment
Pin Number Description Pin Number Description
1Red9+5V
2 Green 10 Detect Cable
3Blue11NC
4 Ground 12 DDC-Serial Data
5 Ground 13 H-Sync
6 R-Ground 14 V-Sync
7 G-Ground 15 DDC-Serial Clock
8 B-Ground
