Epson L3060 series User Manual

Light Situation Solutions
The printer has started in recovery mode
because the
rmware
update failed.
Follow the steps below to try to update the rmware
again.
1. Connect the computer and the printer with a USB
cable. (During recovery mode, you cannot update the
rmware over a network connection.)
2. Visit your local Epson website for further
instructions.
* In some print cycles a very small amount of surplus ink may be collected in the ink pad. To prevent ink leakage
from the pad, the printer is designed to stop printing when the pad has reached its limit. Whether and how oen
this is required will vary according to the number of pages you print, the type of material that you print and the
number of cleaning cycles that the printer performs.
e
need for replacement of the pad does not mean that your
printer has ceased to operate in accordance with its specications. e printer will advise you when the pad
requires replacing and this can only be performed by an authorised Epson Service provider.
e
Epson warranty
does not cover the cost of this replacement.
Related Information
& “Contacting Epson Support” on page 126
& “Installing Applications” on page 92
& “Updating Applications and Firmware” on page 92
Checking the Printer Status - Windows
1. Access the printer driver window.
2.
Click EPSON Status Monitor 3 on the Maintenance tab.
Note:
❏ You can also check the printer status by double-clicking the printer icon on the taskbar. If the printer icon is not
added to the taskbar, click Monitoring Preferences on the Maintenance tab, and then select Register the shortcut
icon to the taskbar.
❏ If EPSON Status Monitor 3 is disabled, click Extended Settings on the Maintenance tab, and then select Enable
EPSON Status Monitor 3.
Related Information
& “Windows Printer Driver” on page 82
Checking the Printer Status - Mac OS
1. Select System Preferences from the menu > Printers & Scanners (or Print & Scan, Print & Fax), and
then select the printer.
2. Click Options & Supplies > Utility > Open Printer Utility.
3. Click EPSON Status Monitor.
You can check the printer status, ink levels, and error status.
User's Guide
Solving Problems
94

Epson L3060 series Specifications

General

Style	Desktop
Color	Black
Control Panel	-
Noise Level	5 B (A) with Epson Premium Glossy Photo Paper / Photo RPM mode - 36 dB (A) with Epson Premium Glossy Photo Paper / Photo RPM mode
Ready: 30 dBA	53.5 dB (A)
Interface Connectors	USB
Wireless Connectivity	WiFi
OS Compatibility	Windows Server 2008
Windows Server 2012 R2	Windows 7
Apple Macintosh OS X 10.5 or later; Linux	Mac OS 10.7.x
Mac OS® X 10.6.8 – 10.10.x8	Windows Server 2008
Windows Server 2008 R2
Windows Vista	Windows 8
Windows 8.1	Windows® 8 / 7 / Vista® / XP® / 2012R2 /
10.6 - 10.10	Mac OS 10.5+
	Android
Maximum: 850 sheets (Main Unit + PF-1100 x2 + MPT)	20 Photo Sheets
Output: 30 sheets	Standard: 550-Sheet Cassette Tray (@75 gsm)
Paper Tray: 100 Sheets Standard	Max: Up to 150 sheets of 20 lb (80 g/m²) plain paper
MPT: Min. A6R - Max. A4R (Legal)	A6 (10.5x14.8 cm)
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	5 x 7"" (12.7 x 17.8 cm)
MPT: Min. A6R – Max. A4 (Legal)	Legal (8.5 in x 14 in)
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	A3 (29.7x42.0 cm)
Manual Feed Slot: Letter	Legal
MPT: 60 - 220 g/m2	Standard / Optional Drawers:
Duplex Printing: 60 - 120 g/m2 (16 - 32 lb)	-
Functions	Print
Features	Decrease TCO (Low running costs with only toner)
Printing Method	Epson Micro Piezo print head
Nozzles	180 Nozzles Black
Print Speed	33 pages/min Monochrome (plain paper 75 g/m²)
-4"" x 6"" borderless photo in as fast as 20 seconds (Draft Mode)1	up to 10.5 ppm - B/W
up to 4 ppm - color duplex	Speed (Simplex) Up to 40 ppm in A4 (Up to 42 ppm in Letter)
Speed (Duplex) Up to 20 ipm in A4 (Up to 20 ipm in Letter)	2.6 pages/min Colour
Maximum Printing Speed: 15 pages/min Monochrome (plain paper 75 g/m²)	45 Seconds per 10 x 15 cm photo (Epson Premium glossy Photo Paper)
First Page Print Time	-
From Sleep: As fast as 18.5 sec	-
Warm Up Time	-
10 Seconds or Less From Sleep	-
Print Resolution	Fast 1200 dpi
Scanner Type	Contact image sensor (CIS)
Scan Speed	300 DPI 2
300 DPI 9	3 msec/line (Color)
Color 35 ipm / 60 ipm (@ 300 dpi)	-
Scan Resolution	1.200 DPI x 2.400 DPI (Horizontal x Vertical)
Enhanced Up to 4	800 dpi
Scan Formats	BMP
Copy Modes	-
Copy Speed	-
Color: 7.2 cpm	up to 7.7 ppm - B/W
up to 3.8 ppm - color	SDMC Up to 40 cpm in A4 (Up to 42 cpm in Letter)
MDMC Up to 35 cpm in A4 (Up to 36 cpm in Letter)	-
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	8W (Stand-by Mode)
Sleep Mode: 0	9W
<1.21 W)	Copying: Approx. 12 W
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	304 mm
Height	169 mm
Width	445 mm
Net Weight	4
