Use a scale that can measure in increments of at
least 0.5 mm (0.02 in.). We also recommend
using a scale that can measure at least 500 mm
(20.0 in.).
E
The screen for entering confirmation results for
the adjustment pattern is displayed.
When Manual(Standard) is selected
Set the values printed under the patterns
selected in A and B, and then press OK.
When Manual(Measurement) is selected
Set the values measured in step 4 for #1 and #2
respectively, and then press OK.
When adjustments are complete, the Home
screen is displayed.
Adjusting the Amount of
Media Fed While Printing
You can perform fine adjustments for the amount of
media fed while printing. Adjusting while printing
allows you to quickly check the adjustment results.
A
During printing, press the following area on the
home screen (adjust while printing).
If the home screen (adjust while printing) is not
displayed, press
(switch screens) on the
home screen.
B
Press / on the screen, or press the /
buttons on the control panel to change the
value.
If the feed amount is too small, black bands
(dark stripes) appear; press the
(or
button) to adjust the feed amount upwards.
In contrast, if the feed amount is too large,
white bands (pale stripes) appear; press the
(or button) to adjust the feed amount
downwards.
C
Check the printing result. If you are not
satisfied with the results, use the
/ , or
the
/ buttons on the control panel to
change the value.
The setting for the currently selected registered
media number is updated.
D
Press to return to the home screen.
Note:
The results of changing the settings are un-done if
you perform any of the following operations.
❏ Restart Media Feed Adjustment.
❏ Execute Clear All Data and Settings.
When you have finished the target printing, we
recommend performing Print Adjustments from the
settings menu.
U “Optimizing Media Settings (Print Head
Alignment and Media Feed Adjustment)” on page 44
SC-F6400 Series/SC-F6400H Series User's Guide
Basic Operations
47
