12 TM-T90 User’s Manual
EnglishEnglish
DIP Switch Tables
TM-T90 Specifications
.
Serial interface
SW Function ON OFF
1-1 Power switch function Disabled Enabled
1-2 Interface condition
selection
by DIP
switch
by memory
switch
1-3 Handshaking XON/XOFF DTR/DSR
1-4 Data word length 7 bits 8 bits
1-5 Parity check Enabled Disabled
1-6 Parity selection Even Odd
1-7
1-8
Transmission speed (See Table A.)
2-1 Reserved Fixed to Off.
Parallel interface
SW Function ON OFF
1-1 Power switch function Disabled Enabled
1-2~
1-8
Reserved Fixed to Off.
2-1 Reserved Fixed to Off.
Table A
Transmission speed (bps)-bits per second 1-7 1-8
2400 ON ON
4800 OFF ON
9600 ON OFF
19200 OFF OFF
Print method Thermal line, 0.141 mm/dot × 0.141 mm/dot (180 dpi × 180 dpi)
Print font 12 × 24/9 × 17
Columns 12 × 24/9 × 17: 42/56 (when roll paper width is 80 mm)
Print width 72.2 mm {2.84"}, 512 dot positions (when paper width is 80 mm)
Character size
(W × H)
12 × 24: Normal/double-high/double-width/quadruple
1.692 × 3.384 mm/1.692 × 6.768 mm/3.384 × 3.384 mm/3.384 × 6.768 mm
{0.07 × 0.13"/0.07 × 0.27"/0.13 × 0.13"/0.13 × 0.27"}
9 × 17: Normal/double-high/double-width/quadruple
1.269 × 2.397 mm/1.269 × 4.794 mm/2.538 × 2.397 mm/2.538 × 4.794 mm
{0.05 × 0.09"/0.05 × 0.19"/0.10 × 0.09"/0.10 × 0.19"}
Character sets 95 alphanumeric, 37 international characters, 128 × 11 graphic
Print speed Normal:
Maximum: 170 mm/s {6.69"/s}
Ladder bar code or two-dimensional code printing:
Maximum: 100 mm/s {3.94"/s}
Four-divided energizing:
Maximum: 70 mm/s {2.76"/s}
Two-color printing:
Maximum: 100 mm/s {3.94"/s}
Paper feed speed Approximately 170 mm/s {6.69"/s}
Line spacing 4.23 mm {1/6"}
Paper dimensions 80 mm (factory setting): 79.5 ± 0.5 × max 102 mm {3.13 ± 0.02 × 4"}
60 mm: 59.5 ± 0.5 × max 102 mm {2.34 ± 0.02 × 4"}
58 mm: 57.5 ± 0.5 × max 102 mm {2.26 ± 0.02 × 4"}
Thermal paper type
ENTPA series
Interface
(compatible)
*1
RS-232/Bi-directional parallel, Dealer option: RS-485, USB, 10 Base-T I/F
Receive data buffer 4KB/45bytes
D.K.D. function 2 drives
Power supply
*2
+24 VDC ± 7%
