Epson TM-U295 Installation Manual

10 TM-U295 Installation Manual
English
8. Then push firmly on the right side and then the left side of the
ribbon cartridge until each side clicks into place.
9. To put the cover back on the printer, first align the left and
insert the tab on the top; then press the bottom until it clicks
into place, as shown below.
Replacing a Used Ribbon
When your printing is not dark enough, it is time to replace the
ribbon.
1. Follow steps 1 through 4 in the “Installing the Ribbon.”
2. Remove the used ribbon by grasping the handle and pulling
straight out, as shown by the arrow in the illustration below.
3. Follow the rest of the steps in “Installing the Ribbon.”
Inserting Paper
CAUTION:
Do not use wrinkled or curled paper.
Use paper that meets the printer’s specifications.
To insert paper, follow these steps:
1. Make sure that a ribbon cassette is installed in the printer.
2. Turn on the printer. The POWER LED comes on.

Epson TM-U295 Specifications

General

Color	No
Maximum number of copies	2 copies
Maximum printing width (columns)	42
Dimensions (WxDxH)	180 x 190.5 x 101.5 mm
Power requirements	24 VDC±10%
Connectivity technology	Wired
Printing media thickness	0.09/0.35 µm
Mean time between failures (MTBF)	180000 h
Safety	UL, CSA C22.2 No. 950
Country of origin	Japan
Electromagnetic compatibility	VCCI class A, FCC class A, CE marking
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	1370 mm
Quantity per pallet	120 pc(s)
Quantity per pallet (UK)	160 pc(s)
Master (outer) case width	300 mm
Quantity per pallet layer	24 pc(s)
Master (outer) case height	405 mm
Master (outer) case length	485 mm
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	32 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	270 mm
Package width	235 mm
Package height	185 mm
Package weight	1845 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	191 mm
Width	180 mm
Height	102 mm
Weight	1600 g
