ESAB Sentinel A60 User Manual

TECHNICAL DATA
Weight
644 gm (1.42 lbs)
Optical Class
1 / 1 / 1 / 1
ADF Dimension (l×h)
132×121 mm (5.20” × 4.76”)
Viewing Area
118×71mm (4.65''×2.8'')
Arc Sensor
4
Light State
DIN 3
Grind State
DIN 3
Welding Mode
Shade No. from 5-8/9-13
Shade Control
Internal, Variable Shade, Digital button Control
Power On/Off
Automatic On / Off
Sensitivity Control
Low — High, Digital button Control
UV/IR Protection
Up to Shade DIN16 at all times
Power Supply
Solar cell. Battery replaceable; 2 × CR2450 lithium battery
Switching Time
1/25,000 s. from Light to Dark
Grinding Mode
Yes via external push button or internal mode selection
Delay (Dark to Light)
0.1 ~ 0.9 s Digital button Control
Low Amperage TIG Rated
≥ 3 amps
Operating Temperature
-10 °C – 65 °C (14 °F – 149 °F)
Storing Temperature
-20 °C – 85°C (-4 °F –185°F)
Certifications
CE (EN166 ; EN175 ; EN379), ISO 16321 V1 +TIG, UKCA
ANSI Z87.1, CSA Z94.3, AS/NZS 1338.1

ESAB Sentinel A60 Specifications

General

Brand	ESAB
Model	Sentinel A60
Category	Welding Accessories
Language	English
