3. Operation
• Power: The refrigerator can be powered by a multi-voltage system utilising either 12/24
Volts or 240 Volts. The electronic module controls the compressor motor and has the
added function of a three stage battery protection. When the input voltage drops below
the minimum, the compressor will cut out; when the voltage comes back up to the cut-
in value, the compressor will restart automatically.
• Battery Protection: The Secop compressor requires over 10.4 Volts (12 Volt System)
or 23.0 Volts (24V System) to operate. If the voltage drops below this the fridge will stop
operating.
• Cable Specification: The DC cables must have a suitable cross-section for their length
(measured from the battery to the unit), according to this table:
Cable Thickness (Area) 12V Max Cable Length 24V Max Cable Length
(mm
2
) AWG (m) () (m) ()
2.5 12 2.5 8 5 16
4 12 4 13 8 26
6 10 6 20 12 39
10 8 10 33 20 66
TRAVELMATE XTREME
