3.Operation Instruction3.Operation Instruction
Control PanelControl Panel
before using it for the first time.
To get the best performance from your dishwasher, read all operating instructions
IMPORTANTIMPORTANT
Dishwasher FeaturesDishwasher Features
9
Back View
1
2
3
4
5
6
7
8
Front view
Dispenser
Cup Shelf
Spray arms
Filter assembly
Inlet pipe connector
Drain pipe
Lower Basket
Inner pipe
Upper Basket
1
Salt Container
5
6
7
8
9
10
3
2
4
10
1 On/Off Button: To turn on/off the power supply.
2 Delay Button : Press the button to add the delay time;
4 Half load function Button: To select Half load
functions. (With this function only be used with
programmes Intensive,Normal,Eco,Glass and 90 min
when you have only about or less than 7 place settings
dishes, and it can save water and energy consumption.
5 Extra Drying function select Button: To select Extra
Drying function.(With this function only be used with
programmes Intensive,Normal,Eco,Glass and 90 min.)
6 Program Button : To Press the button to select
appropriate Program.
7 Start /Pause Button: To start the selected
washing program or pause the washing program
when the machine is working.
8 Program indicators:
3 Child lock button: Press the Button simultaneously more
than 3 second to lock the program, use the same method
to cancel the child lock function.
9 Fuction indicators:
Extra drying indicators:
Half-load indicators:
Child lock indicators:
Rinse Aid indicators:
Add salt indicators:
Dlay time indicators:

Fagor LVF11A Specifications

General

Child lock	Yes
Door color	White
Control type	Buttons
Display type	LED
Product size	Full size (60 cm)
Appliance placement	Freestanding
Noise level	51 dB
Delay start (max)	9 h
Dishwashing programs	Auto, Glass/delicate
Number of place settings	12 place settings
Number of washing programs	6
Water consumption per cycle	11.5 L
Energy consumption per cycle	- kWh
Annual water consumption	3220 L
Annual energy consumption	290 kWh

Weight and Dimensions

Depth	598 mm
Width	600 mm
Height	815 mm
Height under worktop	845 mm
