DELUXE 112
SPECIFICATIONS
Product Release No.: PR 205
Part Number: 120V Version : 022-6702-000
230V : 022-6762-000
100V : 022-6772-000
Product specifications are subject to change without notice
PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 039350 PCB ASSY “DELUXE 112” ALL VERSIONS (STUFFED)
1 028104 BUTTON PUSH SWITCH BLACK (@S1)
1 028577 CABLE ASSY REVERB 30” (@P1-4)
2 028042 CAP AE RDL 50V 2200uF C47,48
1 028458 CAP AE RDL 50V 1uF 20% C53
4 028459 CAP AE RDL 50V 2.2uF 20% C11.33.3.4.35
1 028460 CAP AE RDL 50V 4.7uF 20% C35
6 028465 CAP AE RDL 25V 22uF 20% C6,12,25,27,39,40
4 028471 CAP AE RDL 50V 47uF 20% C37,38,49,50
1 039255 CAP CA 100V 10PF 5% C10
1 038873 CAP CA 100V 22PF 5% C26
1 038698 CAP CA 100V 47PF 5% C29
1 038699 CAP CA 100V 100PF 5% C23
1 038701 CAP CA 50V 470PF 5% C14
1 038874 CAP CA 50V 560PF 5% C17
2 039263 CAP CA 50V 1000PF C3,32
2 039268 CAP CA 50V 4700PF C1,2
1 033579 CAP PF RDL 100V .0015uF 10% C21
2 033580 CAP PF RDL 100V .0022uF 10% C13,28
1 033581 CAP PF RDL 100V .0033uF 10% C20
1 033590 CAP PF RDL 100V .022uF 10% C19
6 033591 CAP PF RDL 100V .033uF 10% C7-9,24,45,46
5 033592 CAP PF RDL 100V .047uF 10% C18,22,51,52,56
2 033596 CAP PF RDL 100V .068uF 10% C54,55
1 036234 CAP PF RDL 100V .015uF 10% C31
2 027278 CAP MPF 63V .1uF 10% C41,42
2 027281 CAP MPF 63V .22uF C5,30
5 027286 CAP MPF 63V .47uF C4,15,16,43,44
1 027937 CONTROL SNAPIN 2K 15A TAPER R14
2 027940 CONTROL SNAPIN 50K 15A TAPER R12,13
2 027941 CONTROL SNAPIN 50K B TAPER R24,33,34,56,
2 027947 CONTROL SNAPIN 100K 30C TAPER R26,35,
1 027949 CONTROL SNAPIN 250K 30C TAPER R38
24 006260 DIODE 1N4448 75PRV CR1-4,9,11,15-21,28-38
4 020534 DIODE 1N5402 RECTOFOER 200V C&F CR22-25
4 028776 DIODE BIAS BYV26D LEAD FORMED CR5-8
2 064089 DIODE 1N4003 200PRV 1AMP
CR13,14
2 027329 DIODE ZENER 1N5228B 3.9V 1/2W CR10,12
2 028119 DIODE ZENER 1M5353B 16V 5W CR26,27
10 025802 FASTON TAB MALE .250”X.032 PCB MT CP1-10
2 026000 FASTON TAB MALE PCB MT .187X.032 CP11,12
2 025996 FUSE CLIP PCB .250 & 5mm FUSE XF1
1 048827 FUSE QA 1-1/4”X1/4” 250V 2AMP F1 (100V/120V ONLY)
To Next Page
