DELUXE 112
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 039352 CHASSIS ASSY “DELUXE 112” 120V (COMPLETE CHASSIS)
1 021709 BUSHING SR .437X.062X13/32 BLK (@SPEAKER CABLE)
1 026116 BUSHING SR .500X.063X7/16 BLK (@REVERB CABLE)
1 026038 BUSHING SR .625X.062X37/64 BLK 100V/120V (@POWER CABLE)
1 010401 BUSHING SR .62X.125X37/64 WHT 230V (@PWR CABLE 230V)
1 026527 CABLE ASSY POWER W/ .187 TABS (POWER CABLE 100V/120V)
1 026528 CABLE ASSY POWER 230V W/.187 TABS (POWER CABLE 230V EXPORT)
1 036479 CABLE ASSY POWER AUST W/.187 TABS (240V AUSTRALIA ONLY)
1 039351 CHASSIS “DELUXE 112” (RAW CHASSIS)
1 028560 END BELL XFMR 85W (@ POWER TRANSFORMER)
1 028499 HEATSINK BAR (COUPLER CHASSIS)
10 026402 KNOB POINTER BLACK
4 028591 NUT ACORN #8-32 (POWER XFORMER MOUNT)
1 039355 PANEL FRONT “DELUXE 112” LEXAN
1 039356 PANEL REAR “DELUXE 112” VINYL
3 028500 SCREW TF 8-32X3/4 SLTD HWH ZI (HEATSINK TO CHASSIS)
2 028937 SCREW TF 6-32X5/8 ROLOK PHP ZI (PCB MOUNTING)
1 038900 SCREW TF 6-32X1/4 PHP ZI (@GROUND LUG)
2 025936 STAND OFF PCB PUSH ON NY 3/8L (PCB MOUNTING)
1 025935 SWITCH POWER DPST (POWER SWITCH)
1 039287 SWITCH POWER DPST EXPORT SEMKO (230V EXPORT ONLY)
4 030007 WASHER LCK INTL 8X.330X.02 ZI (POWER XFORMER MNT)
1 027668 XFORMER POWER 120V 85A (120V DOMESTIC)
1 039357 XFORMER POWER EXPORT (100V/115V/230V)
CABINET ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 040050 CABINET ASSY “DELUXE 112” (COMPLETE CABINET)
2 019279 CAP HANDLE 2-3/16 NI (HANDLE MOUNTING)
1 022491 CLAMP CABLE NYL SCRW MNT 5/16 (REVERB CABLE MNT)
4 026566 CORNER 2 HOLE W/TAB NI (BOTTOM FRONT, TOP REAR)
2 026568 CORNER 3 HOLE NI (BOTTOM REAR)
4 029821 EYELET RFLNDG .215 OD X.315L BRASS (REVERB PAN MOUNT)
4 019275 GLIDE CUSHION INSERT (RUBBER ONLY)
4 019276 GLIDE CAB 1.24X.335 NI (STEEL)
1 040051 GRILLE ASSY “DELUXE 112” (COMPLETE GRILLE)
1 027846 HANDLE 9.25” NO LOGO (RUBBER ONLY, NO INSERT)
1 032524 INSERT HANDLE (SPRING STEEL)
1 011298 NAMEPLATE FENDER SMALL
4 021972 NUT T 10-32X3/4 STR 3 PRNG BLX (SPEAKER/HANDLE MOUNT)
1 028055
REVERB UNIT 800Ω
8EB2C1B DN
(REVERB PAN)
10 026571 SCREW CORNER MOUNTING
4 026577 SCREW M 10-32X1 PHP BLX (SPEAKER MOUNTING)
6 036199 SCREW M 8-32X1-3/16 OHP BLX WX (CHASSIS MOUNT)
4 022244 SCREW M 10-32X1-18 OHP NI (HANDLING MOUNTING)
5 029828 SCREW PB 8X3/2 PHP ZI (REV PAN/CBL CLMP MT)
2 011678 SCREW SMA 8X1-1/2 OHP BLX (GRILLE MOUNTING)
2 018113 SCREW SMA 4X1/2 OHP BLX (NAMEPLATE MOUNTING)
4 026625 SCREW WOOD 8X1 FH (GLIDE MOUNTING)
1 025923
SPEAKER 12” 8Ω
6 029527 WASHER FNSH 8-5/8 FLNGD BLX WX (CHASSIS MOUNT)
FOOTSWITCH ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 028122 FTSW ASSY 2 BTTN REVERB F/LOGO (COMPLETE FOOTSWITCH)
1 028445 PCB ASSY FTSW 2 BUTTON
1 028895 CABLE ASSY FTSW RT ANG 12’ (FTSWT/CABLE)
2 006260 DIODE 1N4448 75PRV CR1,2
1 037036 JACK PHONE PCB MONO CA PREMIUM J1
2 028039 LED 5X5MM RED SLB-55VR3 LD1,2
1 028445 PCB FOOTSWITCH 2 BUTTON (BLANK BOARD)
