12
1
Wi-Fi illuminates when functionality is activated.
Illuminates to indicate that the keys on the control panel are locked. When the
door is closed the display is automatically locked.
Illuminates when the water filter needs replacing.
IIluminates to indicate that Sabbath mode is activated.
Illuminates to indicate key press sounds are deactivated.
2
Allows you to select the fridge or freezer compartment to adjust the temperature.
z
Upper light to indicate the refrigerator compartment is selected.
z
Lower light to indicate the freezer compartment is selected.
3
Alarm mute deactivates the door alarm for 20minutes.
4
Displays the set temperature of the Fridge/Freezer compartments.
To change between Celsius and Fahrenheit on the display:
Press
for sixseconds.
5
Allows you to adjust the temperature of the selected compartment.
6
Displays the set temperature of the Variable Temperature Zone.
To change between Celsius and Fahrenheit on the display:
Press
for sixseconds.
7
Allows you to select the food mode for the Variable Temperature Zone — FRIDGE, CHILL,
SOFT FREEZE
, FREEZER. Lights illuminate to indicate which food mode is selected.
8
Allows you to scroll and select features: FAST FREEZE, BOTTLE CHILL, ICE ON/OFF,
ICE BOOST.
1
2 3
4
5
8
7
6
USING THE CONTROL PANEL (RF605QN & RF605QZ MODELS)
