Slot number Amperage Description
6 5 amp Generic electronic module
(GEM), shift interlock, air
suspension module,
heated backlite (HBL)
relay, steering sensor, trip
computer, compass
7 5 amp Console blower, auxiliary
blower relay coil
8 5 amp GEM, radio, RAP module
9 - Not used
10 - Not used
11 30 amp Front wiper motor, washer
motor
12 5 amp OBDII scan tool connector
13 15 amp Brake on/off switch, brake
pressure switch
14 15 amp Interior lamps, delayed
accessory relay, rear wiper
relays
15 5 amp GEM, passive anti-theft
system (PATS) module
16 20 amp High beam headlamps,
high beam indicator
17 10 amp Heated mirrors, heated
mirror switch
18 5 amp Instrument and switch
illumination
19 10 amp Airbag diagnostic monitor,
instrument cluster
20 5 amp GEM, air suspension
module
21 15 amp Starter relay, junction box
fuse #20
