of fan shroud should locate in clips at bottom of radiator. Secure top of fan shroud with 2 screws and
torque to 6-8 Nm (53-71 lb-in).
19. CAUTION: Fan clutch has left-hand threads so nut must be turned clockwise to remove.
Install fan clutch on water pump hub and torque to 41-135 Nm (30-100 lb-ft) using Tool T84T-6312-C
and Fan Clutch Nut Wrench T84T-6312-D.
20. Reinstall engine air cleaner outlet tube and tighten clamps.
21. Fill engine cooling system to specified level. Refer to Section 03
-03 .
22. Reconnect ground cable at battery.
23. Start vehicle and check for leaks. Allow engine to reach operating temperature and verify no fluid
leaks. Shut off engine, check and correct all fluid levels.
