Examples of unacceptable moisture (usually caused by a lamp water
leak) are:
• Water puddle inside the lamp
• Large water droplets, drip marks or streaks present on the interior of
the lens
Take your vehicle to a dealer for service if any of the above conditions of
unacceptable moisture are present.
Using the right bulbs
Replacement bulbs are specified in the chart below. Headlamp bulbs
must be marked with an authorized “D.O.T.” for North America and an
“E” for Europe to ensure lamp performance, light brightness and pattern
and safe visibility. The correct bulbs will not damage the lamp assembly
or void the lamp assembly warranty and will provide quality bulb burn
time.
Function Number of bulbs Trade number
Park/turn (front) 2 3157 A (amber)
Sidemarker lamps 2 194 NA
Headlamps 2 9007
Fog lamps (if equipped) 2 9145
Hi-mount brake lamp 1 922
Rear stop/turn/tail lamps 2 4157K or 3157K
Rear license plate lamps 2 194
Backup lamps 2 3155
Dome lamp 1 912
Map/dome-SuperCab
(if equipped)
2
904
Map/dome-Regular Cab
(if equipped)
1
904
All replacement bulbs are clear in color except where noted.
To replace all instrument panel lights - see your authorized dealer.
Replacing interior bulbs
Check the operation of all bulbs frequently.
Replacing exterior bulbs
Check the operation of all the bulbs frequently.
Lights
43
2011 Ranger (ran)
Owners Guide, 1st Printing
USA (fus)
