FUSE SPECIFICATION CHART
Pre-Fuse Box
Your vehicle is equipped with a pre-fuse box located in the engine
compartment attached to the positive battery post. This box contains
several high current fuses. If replacement of these high current fuses is
required, see your authorized dealer.
Power Distribution Box
WARNING: Always disconnect the battery before servicing high
current fuses.
WARNING: To reduce risk of electrical shock, always replace the
cover to the power distribution box before reconnecting the
battery or refilling fluid reservoirs.
The power distribution box is located in the engine compartment. It has
high-current fuses that protect your vehicle’s main electrical systems
from overloads.
If the battery has been disconnected and reconnected, see Changing the
Vehicle Battery in the Maintenance chapter.
Lift the release lever at the rear of the cover to remove it.
266 Fuses
2013 C-Max Full Hybrid (34h)
Owners Guide gf, 2nd Printing
USA (fus)
