Supporting Your Vehicle for Service
WARNING: Do not use a jack when working under a vehicle. It
may give way, causing the vehicle to fall and result in property
damage, personal injury or death. Always use floor stands to support
the vehicle.
Prepare the vehicle for service repairs by doing the following:
1. Park the vehicle on a level, concrete floor.
2. Set the parking brake and block the wheels to prevent the vehicle
from moving.
3. Select a jack with a rated capacity sufficient to lift and hold up the
vehicle.
4. Raise the vehicle with the jack applied to the axle(s). DO NOT use
the bumper as a lifting point.
5. Support the vehicle with floor stands under the axle(s). If the axle or
the suspension is being serviced, support the vehicle with floor
stands under the frame side-members, preferably between the axles.
Frame and Tow Hooks
Your vehicle’s chassis is manufactured with frame rails of either HSLA
steel or heat-treated steel. Each must be handled in a specific manner to
make sure maximum service life. Consult the service manual or your
dealer before attempting frame repair or modification.
It is important, particularly on vehicles where the tow hooks are used
frequently, to inspect the front and rear tow hooks for damage or a loose
mounting.
OPENING AND CLOSING THE HOOD
WARNING: The parking brake must be fully set before opening
the hood or possible personal injury may occur.
WARNING: To reduce the risk of the possibility of personal
injury, never stand beneath the hood when it is being raised or
lowered.
WARNING: If you must leave the engine running while checking
under the hood, do not allow any loose clothing, jewelry, hair or
other items to get near moving engine components or possible personal
injury may occur.
Maintenance 215
2013 F-650/750 (f67)
Owners Guide gf, 2nd Printing, March 2013
USA (fus)
