Replacing Brake/Tail/Rear Turn Signal/Reverse/License Plate Lamp
Bulbs
1. Remove the four screws and the
lamp lens from the lamp
assembly.
2. Carefully pull the bulb straight
out of the socket.
3. Reverse the procedure to install
the new bulb.
BULB SPECIFICATION CHART
Replacement bulbs are specified in the chart below. Headlamp bulbs
must be marked with an authorized D.O.T. for North America and an E
for Europe to make sure lamp performance, light brightness and pattern
and safe visibility. The correct bulbs will not damage the lamp assembly
or void the lamp assembly warranty and will provide quality bulb
illumination time.
Function Number of
Bulbs
Trade Number
Headlamps 2 H6054
Front turn signal lamps 2 1157
Front sidemarker lamps, parking
lamps
2 (amber) 194
Brake lamps, tail lamps, stop lamps,
rear turn signals lamps, license plate
lamps
1 (each side) 1157
Back up lamps 2 1156
Front clearance and identification
lamps
5 194
Dome lamp 1 105
To replace all instrument panel lights, see your authorized dealer.
Maintenance 241
2013 F-650/750 (f67)
Owners Guide gf, 2nd Printing, March 2013
USA (fus)
