Type 2
Cluster shown in standard measure – metric clusters similar.
A. Left information display. See Information displays for more
information.
B. Speedometer
C. Right information display. See MyFord Touch® for more information.
WARNING LAMPS AND INDICATORS
These lights can alert you to a vehicle condition that may become
serious enough to cause expensive repairs. Many lights will illuminate
when you start your vehicle to make sure they work. If any light remains
on after starting the vehicle, refer to the respective system warning light
for additional information.
Note: Some warning indicators are reconfigurable telltales (RTT). These
indicators appear in the information display and function the same as a
warning light, but do not display on startup.
A B C
Instrument Cluster 105
2014 Edge (edg)
Owners Guide gf, 2nd Printing, March 2014
USA (fus)
