BULB SPECIFICATION CHART
Replacement bulbs are specified in the chart below. Headlamp bulbs must
be marked with an authorized “D.O.T.” for North America and an “E” for
Europe to ensure lamp performance, light brightness and pattern and safe
visibility. The correct bulbs will not damage the lamp assembly or void the
lamp assembly warranty and will provide quality bulb burn time.
Function Number of bulbs
Trade
number
Headlamp high/low beam
(halogen)
2 HIR2
* HID (high intensity
discharge) headlamp
2 D3S
* Front sidemarker lamp N/A LED
Front park/turn signal
lamp
2
3457NAK
(amber)
Rear turn lamp 2
3757NAK
(amber)
Stop/tail/sidemarker lamp 4
3157K LCP
or 3157K
Backup lamp 2 921
License plate lamp 2 168
* High-mount brake lamp N/A LED
Map lamp 2 W5W
Second row dome/reading
lamp
3 578
Rear courtesy lamp 1 578
Visor vanity lamp 2 37
All replacement bulbs are clear in color except where noted.
To replace all instrument panel lights - see your authorized dealer.
* To replace these lamps - see your authorized dealer.
Maintenance 295
2014 Edge (edg)
Owners Guide gf, 2nd Printing, March 2014
USA (fus)
