Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment
Fuse Panel Description
32 5A Power Mirrors
33 — Not Used
34 10A Transmission Range (TR) Sensor
35 30A RKE Module
36 5A (Cluster, A/C, Illumination, Radio), Steering
Column Assembly
37 — Not Used
38 10A Air Bag Diagnostic Monitor
39 — Not Used
40 30A Modified Vehicle
41 30A Modified Vehicle
42 — Not Used
43 20A C.B. Power Windows*
44 — Not Used
* Either Fuse 21 or Circuit breaker 43 will be present for power
windows.
Power distribution box
The power distribution box is located in the engine compartment. The
power distribution box contains high-current fuses that protect your
vehicle’s main electrical systems from overloads.
Always disconnect the battery before servicing high current
fuses.
Always replace the cover to the Power Distribution Box before
reconnecting the battery or refilling fluid reservoirs.
If the battery has been disconnected and reconnected, refer to the
Battery section of the Maintenance and care chapter.
