Turning on the Front Off-road Camera
System
Your vehicle must meet the following
conditions to turn the system on:
• You must be in off-road mode with
electronic locking differential (ELD)
activated, or in 4L.
See the Off-Road Mode section in the
Driving Hints chapter of this supplement,
and Electronic Locking Differential (ELD)
in the Four-Wheel Drive chapter of your
Owner’s Manual for information on how
to activate these systems.
1. Select the Truck Apps menu in your
information display screen.
2. Select the sub-menu Off-Road
Camera.
3. Press OK to enable and disable the
camera.
The area displayed on the screen may vary
according to the vehicle orientation and
road conditions.
Active and Fixed Guidelines
Fixed guidelines
Active guidelines (will appear in
blue)
A.
Objects in the green zone are
further away
B.
Yellow zoneC.
Objects in the red zone are
closest to your vehicle
D.
Front bumperE.
As objects are getting closer to your
vehicle, they move from the green zone (B)
to the yellow (C) or red zones (D). Look
through your windshield to get a better
field of vision from the front of the vehicle
while driving forward.
Active guidelines
The active guidelines (A) show the path
of intended forward motion of the vehicle
and assist a driver to align with an object
in front of the vehicle.
To use active guidelines, turn the steering
wheel and point the active guidelines
toward an intended path. If the steering
wheel position is changed, the vehicle
might deviate from the original intended
path.
Note: The active guidelines will fade in and
out depending on the steering wheel
position. When the steering wheel position
is straight, the active guidelines are covered
by the static guidelines and are not shown.
Front camera washer control
The front off-road camera washer control
is located on the wiper stalk.
