HEADLAMP CONTROL
Rotate the headlamp control
clockwise to the first position to
turn on the parking lamps.
Rotate clockwise to the second
position
to also turn on the
headlamps.
High beams/Flash-to-pass
High beams:
Push the lever toward the
instrument panel to activate. Pull
the lever toward you to deactivate.
Flash-to-pass:
Pull toward you slightly to activate
and release to deactivate.
Daytime Running Lamps (DRL) (if equipped)
Turns the headlamps on with a reduced output.
To activate:
• the ignition must be turned to the on position and
• the headlamp control is in the
position, parking lamp or autolamp
position.
O
F
F
Lights
50
2012 F-650/750 (f67)
Supplement, 2nd Printing
USA (fus)
