Speedometer: Indicates the current vehicle speed.
• V6 instrument cluster
• V8 instrument cluster
Engine coolant temperature
gauge: Indicates engine coolant
temperature. At normal operating
temperature, the needle will be in
the normal range (between “H” and
“C”). If it enters the red section, the
engine is overheating. Stop the
vehicle as soon as safely possible,
switch off the engine and let the engine cool.
WARNING: Never remove the coolant reservoir cap while the
engine is running or hot.
Odometer: Registers the total miles (kilometers) of the vehicle.
• Base instrument cluster:
• Optional instrument cluster:
Refer to Message center in this
chapter for how to switch the
display from Metric to English.
Instrument Cluster
18
2010 05+ Mustang (197)
Owners Guide, 2nd Printing
USA (fus)
