Ford Racing 347 Series User Manual

Ford Racing 347 Series Sealed Engine Handbook
Issue Date January 25, 2013 Revision #7
No part of this document may be reproduced without the prior agreement and written permission of Ford Racing
24
M-6303-C340 FORGED CRANKSHAFT SCAT ENTERPRISES
M-6316-C351 CRANK DAMPER FORD RACING
M-6500-R302H HYD ROLLER LIFTER EATON CORPORATION
M-6564-B351 ROLLER ROCKER ARM SET FORD RACING
M-6582-E302P VALVE COVER FORD RACING
M-6600-D2 OIL PUMP FORD RACING
M-6605-B302 OIL PUMP SHAFT FORD RACING
EDL-7521 INTAKE MANIFOLD EDELBROCK
M-9439-A50 INTAKE MANIFOLD GSKT. FORD RACING (FelPro 1262S-3)
MS 590 H MAIN BRG. CLEVITE ENGINE PARTS
SBF090030F06 FORGED PISTON & RING SET MAHLE MOTORSPORTS INC.
6441489 WRIST PIN CLIPS PART OF PISTON KIT
6457808 PIN - .927 PART OF PISTON KIT
4035MS-15 RING KIT - 4.030" + .005 PART OF PISTON KIT
9290024 GROOVE LOCK SPACER KIT PART OF PISTON KIT
M-6565-L302 PUSHRODS (16 PACK) FORD RACING
M-6588-A50 CHANNEL KIT ROCKER ARM FORD RACING
M-6529-A302 ROCKER ARM SHIM KIT FORD RACING
42910-S CAM PLATE BOLTS GENERAL FASTENER
6100SB or
M-6622-D347SR
OIL SCREEN
C2OE-6A008-
A2 HEAD DOWELS FORD DEALER SALES
CP6100LT or
M-6675-D347SR
OIL PAN
CHAMP PANS CP 6100LT – OR Ford Racing
M-6675-D347SR
JR 131 DIPSTICK & TUBE CHAMP OIL PANS
M-6261-J351 CAM BEARINGS FORD RACING
VS13264T RUBBER V/C GASKET FEL-PRO
Revisions
Revision 2010-1 1/27/2010
• S347JR Camshaft Part Number corrected – was shown as 35-410-04 – corrected to
35-410-8.
• D347SR/347NST M-6250-F303 camshaft lift at the valve revised to reflect 1.65:1
rocker ratio – lift at valve is 0.528". Was shown at 0.512" which is lift w/ 1.6:1 rocker
ratio. Page 10.
• D347SR/347NST Valve and valve spring dimensions added. Page 10 & 11
• Alternate MSD distributor PN 8579 (Ford Racing PN 85791) added as an optional
OEM distributor. This is a running change January 2010. Pages 16 & 18.
Revision 2010-2 4/5/2010
