2-20
GROUP
2
-BRAKES
3.
Thread
the
front
end of
the
cable
through
the
frame
bracket,
and
en
gage
the
cable
housing
to
the
bracket.
Install
the
U-clip
and
retainer
hook
(Fig.
18).
4.
Insert
the
ball
end
of
the cable
into
the
equalizer
and
tighten the
ad
justing
nut
slightly.
5.
Install
the
rear
drum.
Tighten
the
three
Tinnerman
nuts
that secure
the
drum,
and
install
the
wheel
and
wheel
cover.
6.
Adjust the
parking
brake linkage
as outlined in
Part
2-1,
Section 2.
MAJOR
REPAIR
OPERATIONS
REAR
BRAKE
DRUM
REFINISHING
Minor
scores on a
brake
drum can
be
removed with
a
fine
emery
cloth.
A
drum
that
is
excessively
scored
or
shows a
total
indicator
runout
or
over
0.007
inch
should
be
turned
down.
Remove
only
enough
stock
to
eliminate
the
scores
and true
up
the
drum.
The
refinished
diameter
must
not
exceed
0.060 inch
oversize
(11.150
inches).
If
the
drum
diameter
is
less than
0.030
inch
oversize
(11.120
inches)
after
refinishing,
standard
lining
may
be
installed. If
the
drum
diameter
is
11.120-11.150
inches,
oversize
linings
must
be
installed.
After a
drum
is
turned
down,
wipe
the
refinished
surface
with a
cloth
soaked
in
clean
denatured
alcohol. If
one
drum
is
turned
down,
the
op
posite drum
on the
same
axle
should
also
be cut
down
to the
same size.
REAR
BRAKE
SHOE
RELINING
Brake
linings
that are
worn
to
within
1/32
inch of
the
rivet or
have
been saturated with
grease or
oil
should
be replaced.
Failure to
replace
worn
linings
will
result in
a
scored
drum. When it
is
necessary
to replace
linings,
they
must
also be
replaced on
the
wheel on the
opposite side
of the
car.
Inspect brake shoes for
distortion,
cracks,
or looseness. If
this condition
exists,
the
shoe should be
discarded.
Do not
repair a defective
brake shoe.
1. Wash the
brake
shoes
thorough
ly
in a
clean
solvent.
Remove all
burrs
or
rough
spots
from
the shoes.
2. Check
the
inside
diameter
of
the
brake
drum.
If the
diameter
is less
that
11.120
inches,
standard
linings
may
be
installed. If the
diameter
is
11.120-11.150
inches,
oversize
lining
should be
installed.
3. Position
the
new
lining
on
the
shoe.
Starting
in
the
center,
insert and
secure
the
rivets,
working alternately
towards each
end.
Install
all
parts
supplied
in
the
kit.
Ford
replacement
linings are
ground
and
no
further
grinding
is
required.
4.
Check
the
clearance
between
the
shoe
and
lining.
The
lining
must seat
tightly
against
the
shoe with
not
more
than
0.005 inch
clearance
between
any
two
rivets.
MASTER
CYLINDER
DISASSEMBLY
1.
Press
in
against the
piston re
moving
the
snap
ring
retainer,
and
then
remove
the
piston
assembly,
cup,
spring,
residual
check
valve
and
seat
(Fig.
19).
2.
Remove
secondary
cup
from
the
piston.
Remove
the
cover
by
releasing
the
spring
clips
on
the
sides,
and
re
move
the
hermetic
diaphragm.
ASSEMBLY
1.
Clamp
the
master
cylinder
housing
in
a
vise.
Dip
the
hydraulic
cylinder
parts in
brake
fluid
and
as
semble
the
check
valve
seal,
residual
check
valve,
and piston
return
spring
in
the
bore of
the
cylinder
in
the
order
shown
in
Fie.
19.
COVER
DIAPHRAGM
MASTER
CYLINDER
VALVE
my. PRIMARY
CUP
y/%1
P
; ,
SPRING
SECONDARY
CUP
SNAP
RING
H
1387
-
A
FIG. 19 -Master
Cylinder
-
Disassembled
2. If
the
secondary
piston
cup
was
removed
from the
piston,
dip
the
cup
in brake fluid and assemble the
cup
in
the
groove of the piston
with the
lip
of
the
cup
as
shown.
3. Place the
primary
cup
on
the end
of the piston
assembly,
and
guide
it
into
the cylinder
bore.
4. Press in
against the
piston
to
compress the
spring
while
seating
the
snap
ring
in
the groove in
the
cylinder
bore.
5.
Install a
new
diaphragm
(only
if
the
old one
is
defective)
in
the
cover,
and attach the
cover
to the cylinder
with the
spring
clips.
DISC
BRAKE
CALIPER
DISASSEMBLY
Do not
remove the
bridge
bolts that
hold
the
two
halves of
the
caliper
together.
The
two
caliper
housings are
shown
separated in
Fig. 21
for
il
lustration
purposes only.
1.
Remove
the
caliper
assembly
from the
car
as
outlined
in
Section
2.
2.
Remove
the
two
attaching
bolts
and the
caliper splash
shield (Fig. 21).
(Fig.
21).
3.
Remove
the
two shoe
and
lining
assemblies.
4.
Remove
the
flexible
brake
hose
from
the
caliper.
5.
Remove
the
external
transfer
tube.
6.
Remove
the
four
dust
boots
from
the
caliper
housings
and
piston
grooves.
7.
Clamp
the
caliper
in a
vise
and
secure it
by
the
mounting
flanges on
the
inboard
housing
(Fig.
20).
8.
Remove
the
four
pistons
from
the
cylinder
bores
with
the
special
tool
shown
in
Fig.
20.
To
prevent
cocking
with
consequent
damage
to
the
piston
or
bore,
rotate
the
piston
with
the
tool
while
pulling
it
outward at
the
same
time.
Be
careful
to
avoid
scratching
or
damaging
the
outside
