Installation
1918
Wall Mount Option
1. Mark the location of the holes using the mounting bracket
2. Drill holes for the anchors
3. Insert the anchors and then screw in the screws with 2mm exposed
4. Fasten the mounting bracket
5. Position the device and slide into place
6. Plug the provided power cable into the rear of the unit and then into a grounded
electrical outlet or separate power source
Desktop Option
1. Place the unit on a flat, clean and stable surface
2. Ensure there is at least 1.5in of clearance for adequate airflow
3. Plug the provided power cable into the rear of the unit and then into a grounded
electrical outlet or separate power source
1.5in
1.5in
1.5in
1.5in
