Error code chart
Error
code Fault condition Check
E11 Fill time too long. Refer to test (1).
E13 Water leak in tub or air leak in air bell. Refer to test (2).
E21 Water not pumping out fast enough. Refer to test (3).
E23 Drain pump relay on control board failed, wire off pump or pump Replace console control board, wire or
defective. pump.
E24 Drain pump relay on control board failed. Replace console control board.
E31 Pressure sensor not communicating with control board. Refer to test (4).
E35 Pressure sensor indicates water overfill. Refer to test (5).
E36 Console control board problem. Replace console control board.
E38 Air chamber clogged or pressure sensor defective. Check air chamber, rpl press. sensor.
E41 Control board thinks the door switch is open. Refer to test (6).
E43 Console control board thinks the door locking device has failed. Refer to test (7).
E44 Console control board problem. Replace console control board.
E45 Console control board problem. Replace console control board.
E46 Console control board problem. Replace console control board.
E47 Console control board thinks the door PTC circuit is open in spin. Refer to test (7).
E48 Console control board thinks the door PTC circuit is closed. Refer to test (7).
E52 Bad signal from tacho generator. Refer to test (8).
E56 High motor current. Refer to test (9).
E57 High current on inverter. Refer to test (9).
E58 High current on motor phase. Refer to test (9).
E59 No tacho signal for 3 seconds. Refer to test (10).
E5A High temperature on heat sink caused by overloading. Test first-if bad-rpl speed control brd.
E5B High temperature on heat sink. Replace speed control board.
E5C High temperature on heat sink. Replace speed control board.
E5D Communication problem. Refer to test (11).
E5E Communication problem. Refer to test (11).
E5F Communication problem. Refer to test (11).
E66 Heating element relay failure. Refer to test (14).
E67 Input voltage on microprocessor incorrect. Refer to test (15).
E68 Current leakage to ground on heater or fuse opened. Refer to test (14 & 15).
E71 Wash NTC failure. Refer to test (15).
E74 Wash temperature does not increase. Wire off NTC - rpl water valve.
E75 Water temperature sensor circuit. Refer to test (12).
E82 Console control board problem. Replace console control board.
E83 Console control board problem. Replace console control board.
E91 Comunnication error between UI board and console control board. Refer to test (16).
E93 Console control board problem. Replace console control board.
E94 Console control board problem. Replace console control board.
E95 Communication error. Replace console control board.
E97 Console control board problem. Replace console control board.
E98 Console control board problem. Replace console control board.
EB1 Incoming power frequency out of limits. Refer to test (13).
EB2 Incoming line voltage above 130 VAC. Check voltage at outlet. If < 130VAC,
replace the console control board.
EB3 Incoming line voltage below 90 VAC. Check voltage at outlet. If > 90VAC,
replace the console control board.
EBE Console control board problem. Replace console control board.
EBF Console control board problem. Replace console control board.
EF1 Clogged drain pump. Unclog the drain pump.
EF2 Too much soap. Advise customer to reduce the amount
of soap they are using.

Frigidaire FAFW3801LB Specifications

General

Style	Front-Loading
Color	White
Washer Capacity	3.26 cu ft
Dryer Capactity	-
Max Spin Speed	1100 RPM
Spin Speeds	4 (High
Spin Class	C
Number of Cycles	5
Cycle Selections	Casual
Wash	Baby
Options	Time Remaining Display
Hours	Child Lock
Noise level	-
Temperature Selections	5 (Hot
Energy Class	-
Annual Energy Consumption	99 kWh
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	60 Hz
Current	15 A

Weight and Dimensions

Depth	30 5/16 in
Height	36 in
Width	27 in
Net Weight	222 lbs
