1
T
op Panel Sub
Assy
9374417032
Ref.
Description
Parts number
9
2009.01.14
59
Fan Guard Cover
93781
1
101
1
7
Right Panel Sub
Assy
9374416158
8
Pipe Cover Rear
9378862012
--
Protective Net
9375381042
--
Emblem Rear
9351355005
6
Pipe Cover Front
9378861015
5
Sevice Panel Sub
Assy
9374415076
4
Grip Side
9374173013
3
Fan Guard
9374330010
2
Front Panel
9374094028
P
ARTS
OUTDOOR UNIT
5
8
6
7
3
9
3
4
2
1
59
61
Table of Contents
Table of Contents
1
Specifications
2
Electrical Data
2
Cassette Type
2
Fan Motor
2
Ceiling Type
3
Measurement
3
Outline and Dimensions
6
Circuit Diagram
11
Indoor Pcb Circuit Diagram
15
To Controller Pcb Assembly
18
Power Supply Pcb Assembl
19
Controller Pcb Assy
19
Duct Type
24
Outdoor Pcb Circuit Diagram
27
Self-Diagnosis
34
Troubleshooting at the Remote Control LCD
34
Remote Control
34
Error Detection
34
Troubleshooting with the Indoor Display
35
Check Items before Performing the Test Run
36
Operating Procedures for the Test Run
36
Test Run Method
36
Controller PCB Assy of Control Unit
36
Display While an Error Code Is Blinking
37
Display When an Error Occurs
37
How to Check Error Code
37
Error Code Display
37
Special Installation Setting
38
Pump down Procedure
38
Preparation for Pump down
38
Parts (Indoor Unit)
39
Parts (Outdoor Unit)
60
Decoration Panel
64
Accessories
64
