6. OUTDOOR FAN CONTROL
(1). Fan Speed
Cooling Dry Heating
( Table 6 : Outdoor fan speed )
*
The outdoor fan speed mentioned avobe depends on the compressor frequency.
(When the compressor frequency increases, the outdoor fan speed also changes to the higher
speed. When the compressor frequescy decreases, the outdoor fan speed also changes to the
lower speed.)
*
It runs at 500(A-D ZONE)/200(E,F ZONE) rpm for 20/60 seconds after starting up the outdoor fan.
*
After the defrost control is operated on the heating mode, the fan speed keeps at the higher speed
as table 7 without relating to the compressor frequency.
05-07
ZONE
Refer to Fig1.
(rpm)
ASU15/18RLQ
A-D
E
F
860/820/670/500
400~150
280~150
500
400~150
280~150
820/750/670/450
(2). Fan Speed
*
Outdoor temperature falls, and if it becomes E and F zone(
Refer to Fig1), rotations of fan speed
will fall.
( Table 7 : Outdoor fan speed after the defrost )
ASU15/18RLQ
Min
950rpm
To Next Page
