PARTS
8
4
4
6
5
7
3
9
1
2
INDOOR UNIT
2012.10.30 11
4
8
10
7
9
Front Panel 9332545012
3 Bracket Panel 9332556001
1
Wire Cover 9332544008
5
Wire Shield 9332555004
Remote Control 9332820003
2 Remote Control Holder 9312653010
Intake Grille (FUJITSU) 9332818093
6 Receiver Window 9332546019
11 Panel Cover 9332559002
Ref. Description Part number
Air Filter 9332549003
Louver 9332548006
10
11
