1. Specifications
Type Inverter heat pump
Model name AOYG07LLCE AOYG09LLCE AOYG12LLCE
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Starting current A 3.0 3.5 5.4
Fan
Airflow rate
Cooling
m
3
/h
1,670 1,830
Heating 1,470 1,600
Type × Q'ty Propeller fan × 1
Motor output W 23
Sound pressure level *1
Cooling
dB (A)
47 50
Heating 48 51
Sound power level
Cooling
dB (A)
61 65
Heating 61 65
Heat exchanger type
Dimensions
(H × W × D)
mm
650 × 504 × 18.2
642 × 504 × 18.2
612 × 504 × 18.2
Fin pitch 1.30 1.40
Rows × Stages 1 × 24 2 × 24
Pipe type Copper
Fin type
Type (Material) Corrugate (Aluminum)
Surface treatment Corrosion resistance (Blue fin)
Compressor
Type × Q'ty Rotary × 1
Motor output W 610 670
Refrigerant
Type (Global warming potential) R410A (1975)
Charge g 650 850
Refrigerant oil
Type POE (VG74)
Amount
cm
3
370
Enclosure
Material Steel sheet
Color
Beige
Approximate color of MUNSELL 10YR7.5/1.0
Dimensions
(H × W × D)
Net
mm
535 × 663 × 293
Gross 595 × 790 × 395
Weight
Net
kg
24 26
Gross 27 29
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8)
Method Flare
Pre-charge length
m
15
Max. length 20
Max. height difference 15
Operation range
Cooling
°C
-10 to 43
Heating -15 to 24
Drain hose
Material LDPE
Size mm Ø 13.0 (I. D.), Ø 16.0 to Ø 16.7 (O. D.)
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m.
• Protective function might work when using it outside the operation range.
• *1: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
DESIGN & TECHNICAL MANUAL
- 24 -
OUTDOOR UNIT
AOYG07-12LLCE
